| Broj dijela | VVX09F035M20 |
| Marka | Panasonic |
| Veličina | 8.9 |
| Primjena | PAD |
| Rezolucija | 1920×1200 |
| Sastav | LCM |
| Svjetlina | 350 |
| CR | 800:1 |
| Boje | 16.7M |
| Pozadinsko osvjetljenje | WLED |
| Sučelje | eDP |
| marka panela | Panasonic |
| panelni model | VVX09F035M20 |
| vrsta panela | a-Si TFT-LCD , LCM |
| veličina ploče | 8.9 inch |
| rezolucija | 1920(RGB)×1200 , WUXGA |
| način prikaza | IPS-Pro, Normally Black, Transmissive |
| aktivno područje | 191.52×119.7 mm |
| obris | 203.5×135.9×4.8 mm |
| površinski | Hard coating |
| svjetlina | 350 cd/m² (Typ.) |
| omjer kontrasta | 800:1 (Typ.) |
| boje prikaza | 16.7M (6-bit + Dithering), CIE193150% |
| vrijeme odziva | 30 (Max.)(Tr+Td) |
| kut gledanja | 80/80/80/80 (Min.)(CR≥80)(L/R/U/D) |
| frekvencija | 60Hz |
| tip svjetiljke | 7S5PWLEDWithout Driver |
| signalno sučelje | eDP (2 Lanes), 30 pins |
| ulazni napon | 3.3V (Typ.) |
| primjena | PAD |
