| Broj dijela | HV089WU1-1E0 |
| Marka | HYDIS |
| Veličina | 8.9 |
| Primjena | PAD |
| Rezolucija | 1920×1200 |
| Sastav | LCM |
| Svjetlina | 450 |
| CR | 800:1 |
| Boje | 16.7M |
| Pozadinsko osvjetljenje | WLED |
| Sučelje | MIPI |
| marka panela | HYDIS |
| panelni model | HV089WU1-1E0 |
| vrsta panela | a-Si TFT-LCD , LCM |
| veličina ploče | 8.9 inch |
| rezolucija | 1920(RGB)×1200 , WUXGA |
| način prikaza | HFFS, Normally Black, Transmissive |
| aktivno područje | 191.52×119.7 mm |
| obris | 203.5×135.9×5 mm |
| površinski | Antireflection |
| svjetlina | 450 cd/m² (Typ.) |
| omjer kontrasta | 800:1 (Typ.) |
| boje prikaza | 16.7M (6-bit + Hi-FRC) |
| vrijeme odziva | 30 (Typ.)(Tr+Td) |
| kut gledanja | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| frekvencija | 60Hz |
| tip svjetiljke | 7S5PWLEDWithout Driver |
| signalno sučelje | MIPI (4 data lanes), 45 pins |
| ulazni napon | 3.3V (Typ.) |
| primjena | PAD |
