| Broj dijela | TX15D02VM0CAA |
| Marka | KOE |
| Veličina | 5.8 |
| Primjena | CNS |
| Rezolucija | 400×240 |
| Sastav | LCM |
| Svjetlina | 450 |
| CR | 800:1 |
| Boje | 262K |
| Pozadinsko osvjetljenje | WLED |
| Sučelje | TTL |
| marka panela | HITACHI |
| panelni model | TX15D02VM0CAA |
| vrsta panela | a-Si TFT-LCD , LCM |
| veličina ploče | 5.8 inch |
| rezolucija | 400(RGB)×240 , WQVGA |
| način prikaza | IPS Pro, Normally Black, Transmissive |
| aktivno područje | 126×75.6 mm |
| obris | 145×90×12 mm |
| površinski | |
| svjetlina | 450 cd/m² (Typ.) |
| omjer kontrasta | 800:1 (Typ.) |
| boje prikaza | 262K (6-bit), CIE193160% |
| vrijeme odziva | 45 (Max.)(Tr+Td) |
| kut gledanja | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| frekvencija | 60Hz |
| tip svjetiljke | 3S4PWLEDEmbedded (LED Driver) |
| signalno sučelje | CMOS (1 ch, 6-bit), 40 pins |
| ulazni napon | 3.3V (Typ.) |
| primjena | CNS |
