| Broj dijela | L5S30883P00 |
| Marka | SANYO |
| Veličina | 4.5 |
| Primjena | CNS |
| Rezolucija | 480×240 |
| Sastav | LCM |
| Svjetlina | 400 |
| CR | 300:1 |
| Boje | 262K |
| Pozadinsko osvjetljenje | WLED |
| Sučelje | TTL |
| marka panela | SANYO |
| panelni model | L5S30883P00 |
| vrsta panela | a-Si TFT-LCD , LCM |
| veličina ploče | 4.5 inch |
| rezolucija | 480(RGB)×240 , WQVGA |
| način prikaza | TN, Normally White, Transmissive |
| aktivno područje | 99.36×56.04 mm |
| obris | 112.7×70.2 mm |
| površinski | Glare (Haze 0%) |
| svjetlina | 400 cd/m² (Typ.) |
| omjer kontrasta | 300:1 (Typ.) |
| boje prikaza | 262K (6-bit) |
| vrijeme odziva | 10/20 (Typ.)(Tr/Td) |
| kut gledanja | 55/55/45/55 (Typ.)(CR≥10)(L/R/U/D) |
| frekvencija | 60Hz |
| tip svjetiljke | WLEDEmbedded (LED Driver) |
| signalno sučelje | Parallel RGB (1 ch, 6-bit), 40 pins |
| ulazni napon | 3.3V (Typ.) |
| rohs: | |
| primjena | CNS |
