| Broj dijela | P070BAG-CM1 |
| Marka | Innolux |
| Veličina | 7.0 |
| Primjena | CNS |
| Rezolucija | 1024×600 |
| Sastav | LCM |
| Svjetlina | 500 |
| CR | 800:1 |
| Boje | 262K/16.7M |
| Pozadinsko osvjetljenje | WLED |
| Sučelje | LVDS |
| marka panela | INNOLUX |
| panelni model | P070BAG-CM1 |
| vrsta panela | a-Si TFT-LCD , LCM |
| veličina ploče | 7.0 inch |
| rezolucija | 1024(RGB)×600 , WSVGA |
| način prikaza | TN, Normally White, Transmissive |
| aktivno područje | 154.214×85.92 mm |
| obris | 164.9×100×5.1 mm |
| površinski | Hard coating |
| svjetlina | 500 cd/m² (Typ.) |
| omjer kontrasta | 800:1 (Typ.) |
| boje prikaza | 262K/16.7M (6-bit / 6-bit + Dithering), CIE193170% |
| vrijeme odziva | 10/15 (Typ.)(Tr/Td) |
| kut gledanja | 75/75/70/75 (Typ.)(CR≥10)(L/R/U/D) |
| frekvencija | 60Hz |
| tip svjetiljke | WLEDWithout Driver |
| signalno sučelje | LVDS (1 ch, 6/8-bit), 40 pins |
| ulazni napon | 3.3/11.0/20.0/-6.8V (Typ.)(DVDD/AVDD/VGH/VGL) |
| primjena | CNS |
