| Broj dijela | LB070WV1-TD17 |
| Marka | LG Display |
| Veličina | 7.0 |
| Primjena | DPF |
| Rezolucija | 800×480 |
| Sastav | LCM |
| Svjetlina | |
| CR | |
| Boje | 262K |
| Pozadinsko osvjetljenje | CCFL |
| Sučelje | TTL |
| marka panela | LG Display |
| panelni model | LB070WV1-TD17 |
| vrsta panela | a-Si TFT-LCD , LCM |
| veličina ploče | 7.0 inch |
| rezolucija | 800(RGB)×480 , WVGA |
| način prikaza | TN, Normally White, Transmissive |
| aktivno područje | 152.4×91.44 mm |
| površinski | |
| svjetlina | |
| omjer kontrasta | |
| boje prikaza | 262K (6-bit) |
| vrijeme odziva | |
| kut gledanja | |
| tip svjetiljke | 2 pcsCCFL |
| primjena | DPF |
| LB070WQ4-TM01 | LG Display | 7.0 | 480×234 |
| LB070WQ4-TM06 | LG Display | 7.0 | 480×234 |
| LB070WQ5-TD01 | LG Display | 7.0 | 480×240 |
| LB070WQ6-TD01 | LG Display | 7.0 | 400×234 |
| LB070WV1-TD17 | LG Display | 7.0 | 800×480 |
| LB070WV3-SD02 | LG Display | 7.0 | 800×480 |
| LB070WV4-TJ01 | LG Display | 7.0 | 800×480 |
| LB070WV6-TD06 | LG Display | 7.0 | 800×480 |
| LB070WV7-TD01 | LG Display | 7.0 | 800×480 |
| LB070WV7-TL01 | LG Display | 7.0 | 800×480 |
| A070FW05 V1 | AUO | 7.0 | 480×234 |
| AT070TN01 | Innolux | 7.0 | 480×234 |
| HSD084ISN1-A01 | HannStar | 8.4 | 800×600 |
| HSD100IFW1-A00 | HannStar | 10.1 | 1024×600 |
| HSD100IFW1-F01 | HannStar | 10.1 | 1024×600 |
| HSD100IXN1-A00 | HannStar | 10.0 | 1024×768 |
| LB080WV3-B1 | LG Display | 8.0 | 800×480 |
| LQ085Y3DG01 | SHARP | 8.5 | 800×480 |
| LTA104S1-L01 | Samsung | 10.4 | 800×600 |
| PW070XU3 | E Ink | 7.0 | 480×234 |
