| Broj dijela | G070Y3-T01 |
| Marka | Innolux |
| Veličina | 7.0 |
| Primjena | IA |
| Rezolucija | 800×480 |
| Sastav | LCM |
| Svjetlina | 600 |
| CR | 650:1 |
| Boje | 262K |
| Pozadinsko osvjetljenje | WLED |
| Sučelje | TTL |
| marka panela | CMO |
| panelni model | G070Y3-T01 |
| vrsta panela | a-Si TFT-LCD , LCM |
| veličina ploče | 7.0 inch |
| rezolucija | 800(RGB)×480 , WVGA |
| način prikaza | TN, Normally White, Transmissive |
| aktivno područje | 156×82.8 mm |
| obris | 168×94×6.65 mm |
| površinski | Antiglare (Haze 25%), Hard coating (3H) |
| svjetlina | 600 cd/m² (Typ.) |
| omjer kontrasta | 650:1 (Typ.) |
| boje prikaza | 262K (6-bit), CIE193160% |
| vrijeme odziva | 5/11 (Typ.)(Tr/Td) |
| kut gledanja | 70/70/60/60 (Typ.)(CR≥10)(L/R/U/D) |
| frekvencija | 60Hz |
| tip svjetiljke | 9S3PWLEDWithout Driver |
| signalno sučelje | TTL (1 ch, 6-bit), 50 pins |
| ulazni napon | 3.3/10.5/18/-7V (Typ.)(VCC/AVDD/VGH/VGL) |
| primjena | IA |
