| Broj dijela | NL10276AC24-05 |
| Marka | NLT |
| Veličina | 12.1 |
| Primjena | DMPC |
| Rezolucija | 1024×768 |
| Sastav | LCM |
| Svjetlina | 200 |
| CR | 150:1 |
| Boje | Full color |
| Pozadinsko osvjetljenje | CCFL |
| Sučelje | Analog |
| marka panela | NEC |
| panelni model | NL10276AC24-05 |
| vrsta panela | a-Si TFT-LCD , LCM |
| veličina ploče | 12.1 inch |
| rezolucija | 1024(RGB)×768 , XGA |
| način prikaza | TN, Normally White, Transmissive |
| aktivno područje | 245.76×184.32 mm |
| obris | 290×225×17 mm |
| površinski | |
| svjetlina | 200 cd/m² (Typ.) |
| omjer kontrasta | 150:1 (Typ.) |
| boje prikaza | Full color , CIE193140% |
| vrijeme odziva | 40 (Max.)(Tr) |
| kut gledanja | 50/50/20/20 (Typ.)(CR≥10)(L/R/U/D) |
| tip svjetiljke | 2 pcsCCFLEmbedded (Inverter) |
| signalno sučelje | Analog RGB, 31 pins |
| ulazni napon | 3.3/12V (Typ.)(VCC/VDD) |
| primjena | DMPC |
