| Broj dijela | N080ICE-GB0 Rev.A1 |
| Marka | Innolux |
| Veličina | 8.0 |
| Primjena | PAD |
| Rezolucija | 800×1280 |
| Sastav | LCM |
| Svjetlina | 400 |
| CR | 800:1 |
| Boje | 16.7M |
| Pozadinsko osvjetljenje | WLED |
| Sučelje | MIPI |
| marka panela | INNOLUX |
| panelni model | N080ICE-GB0 Rev.A1 |
| vrsta panela | a-Si TFT-LCD , LCM |
| veličina ploče | 8.0 inch |
| rezolucija | 800(RGB)×1280 , WXGA |
| način prikaza | AAS, Normally Black, Transmissive |
| aktivno područje | 107.64×172.224 mm |
| obris | 114.58×184.09×4.06 mm |
| površinski | Hard coating, Antireflection |
| svjetlina | 400 cd/m² (Typ.) |
| omjer kontrasta | 800:1 (Typ.) |
| boje prikaza | 16.7M (8-bit), CIE193160% |
| vrijeme odziva | 20 (Typ.)(Tr+Td) |
| kut gledanja | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| frekvencija | 60Hz |
| tip svjetiljke | 4 stringsWLEDWithout Driver |
| signalno sučelje | MIPI (4 data lanes), 31 pins |
| ulazni napon | 1.8/3.3V (Typ.)(VDDI/VCI) |
| primjena | PAD |
