| Broj dijela | LD080UX1-SMA2 |
| Marka | LG Display |
| Veličina | 8.0 |
| Primjena | PAD |
| Rezolucija | 1200×1600 |
| Sastav | LCM |
| Svjetlina | 400 |
| CR | |
| Boje | 16.7M |
| Pozadinsko osvjetljenje | WLED |
| Sučelje | |
| marka panela | LG Display |
| panelni model | LD080UX1-SMA2 |
| vrsta panela | a-Si TFT-LCD , LCM |
| veličina ploče | 8.0 inch |
| rezolucija | 1200(RGB)×1600 , UXGA |
| način prikaza | IPS, Normally Black, Transmissive |
| površinski | |
| svjetlina | 400 cd/m² (Typ.) |
| omjer kontrasta | |
| boje prikaza | 16.7M (8-bit), CIE193160% |
| vrijeme odziva | |
| kut gledanja | |
| tip svjetiljke | WLED |
| rohs: | |
| primjena | PAD |
