| Broj dijela | LD080WX2-SMN1 |
| Marka | LG Display |
| Veličina | 8.0 |
| Primjena | PAD |
| Rezolucija | 800×1280 |
| Sastav | LCM |
| Svjetlina | 330 |
| CR | 800:1 |
| Boje | 16.7M |
| Pozadinsko osvjetljenje | WLED |
| Sučelje | MIPI |
| marka panela | LG Display |
| panelni model | LD080WX2-SMN1 |
| vrsta panela | a-Si TFT-LCD , LCM |
| veličina ploče | 8.0 inch |
| rezolucija | 800(RGB)×1280 , WXGA |
| način prikaza | IPS, Normally Black, Transmissive |
| aktivno područje | 107.64×172.224 mm |
| obris | 114.6×184.55×4.25 mm |
| površinski | Hard coating |
| svjetlina | 330 cd/m² (Typ.) |
| omjer kontrasta | 800:1 (Typ.) |
| boje prikaza | 16.7M (8-bit), CIE193150% |
| vrijeme odziva | 35 (Typ.)(Tr+Td) |
| kut gledanja | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| frekvencija | 60Hz |
| tip svjetiljke | 7S3PWLEDWithout Driver |
| signalno sučelje | MIPI (4 data lanes), 34 pins |
| ulazni napon | 1.8/5.2/-5.2V (Typ.)(VDDI/AVDD/AVEE) |
| primjena | PAD |
| AT080TN43 | Innolux | 8.0 | 800×600 |
| B080UAN01.2 | AUO | 8.0 | 1200×1920 |
| CLAA080LA0ACW | CPT | 8.0 | 800×480 |
| EC080SC2 | E Ink | 8.0 | |
| EJ080NA-04B | Innolux | 8.0 | 1024×768 |
| HSD080IDW1-A00 | HannStar | 8.0 | 800×480 |
| LD080WX2-SMN1 | LG Display | 8.0 | 800×1280 |
| LM64P122 | SHARP | 8.0 | 640×480 |
| LQ080V3DG01 | SHARP | 8.0 | 640×480 |
| TX20D16VM2BAA | KOE | 8.0 | 800×480 |
| A090PAN01.0 | AUO | 9.0 | 900×1440 |
| B080XAN02.0 | AUO | 7.9 | 768×1024 |
| B101EAN01.2 | AUO | 10.1 | 1280×800 |
| CLAA080WQ02 XN | CPT | 8.0 | 800×1280 |
| CLAA101FP01 | CPT | 10.1 | 1920×1200 |
| HV101WU1-1E3 | HYDIS | 10.1 | 1920×1200 |
| HX121WX1-103 | HYDIS | 12.1 | 1280×800 |
| LP097QX1-SPA2 | LG Display | 9.7 | 2048×1536 |
| LP097X02-SLQ1 | LG Display | 9.7 | 1024×768 |
| N080JCE-G41 | Innolux | 8.0 | 1200×1920 |
