| Broj dijela | N080ICE-GB0 Rev.A0 |
| Marka | Innolux |
| Veličina | 8.0 |
| Primjena | PAD |
| Rezolucija | 800×1280 |
| Sastav | LCM |
| Svjetlina | 400 |
| CR | 1000:1 |
| Boje | 16.7M |
| Pozadinsko osvjetljenje | WLED |
| Sučelje | MIPI |
| marka panela | INNOLUX |
| panelni model | N080ICE-GB0 Rev.A0 |
| vrsta panela | a-Si TFT-LCD , LCM |
| veličina ploče | 8.0 inch |
| rezolucija | 800(RGB)×1280 , WXGA |
| način prikaza | AAS, Normally Black, Transmissive |
| aktivno područje | 107.64×172.224 mm |
| obris | 114.6×184.1×3.5 mm |
| površinski | Glare (Haze 0%), Hard coating, Antireflection |
| svjetlina | 400 cd/m² (Typ.) |
| omjer kontrasta | 1000:1 (Typ.) |
| boje prikaza | 16.7M (8-bit), CIE193160% |
| vrijeme odziva | 25 (Typ.)(Tr+Td) |
| kut gledanja | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| frekvencija | 60Hz |
| tip svjetiljke | WLEDWithout Driver |
| signalno sučelje | MIPI (4 data lanes), 39 pins |
| ulazni napon | 1.8/3.3V (Typ.)(VCC/VDDI) |
| primjena | PAD |
| CLAA080JA11CW | CPT | 8.0 | 480×220 |
| HJ080IA-01F | Innolux | 8.0 | 1024×768 |
| LA080WV4-SD03 | LG Display | 8.0 | 800×480 |
| LB080WV4-TA01 | LG Display | 8.0 | 800×480 |
| N080ICE-GB0 Rev.A0 | Innolux | 8.0 | 800×1280 |
| N080ICE-GB0 Rev.A1 | Innolux | 8.0 | 800×1280 |
| N080ICE-GB0 Rev.B1 | Innolux | 8.0 | 800×1280 |
| N080ICE-GB0 Rev.C1 | Innolux | 8.0 | 800×1280 |
| N080ICE-GB0 Rev.C2 | Innolux | 8.0 | 800×1280 |
| N080ICE-GB1 | Innolux | 8.0 | 800×1280 |
| B101UAN01.E | AUO | 10.1 | 1920×1200 |
| BP070WS1-500 | BOE | 7.0 | 1024×600 |
| BP101WX1-400 | BOE | 10.1 | 1280×800 |
| LP125WH2-SPT1 | LG Display | 12.5 | 1366×768 |
| LTL070NL01-002 | Samsung | 7.0 | 1024×600 |
| LTL090CL01-002 | Samsung | 9.0 | 1920×1280 |
| LTN101AL03-001 | Samsung | 10.1 | 1280×800 |
| N070ICE-GB2 | Innolux | 7.0 | 800×1280 |
| TPF0702002N | JDI | 7.0 | 1200×1920 |
| VVX11F019G00 | Panasonic | 11.6 | 1920×1080 |
