| Broj dijela | LB080WV4-TA01 |
| Marka | LG Display |
| Veličina | 8.0 |
| Primjena | CNS |
| Rezolucija | 800×480 |
| Sastav | LCM |
| Svjetlina | 500 |
| CR | 400:1 |
| Boje | 262K |
| Pozadinsko osvjetljenje | CCFL |
| Sučelje | Analog |
| marka panela | LG.Philips LCD |
| panelni model | LB080WV4-TA01 |
| vrsta panela | a-Si TFT-LCD , LCM |
| veličina ploče | 8.0 inch |
| rezolucija | 800(RGB)×480 , WVGA |
| način prikaza | TN, Normally White, Transmissive |
| aktivno područje | 176.64×99.36 mm |
| obris | 216.5×121 mm |
| površinski | Antiglare |
| svjetlina | 500 cd/m² (Typ.) |
| omjer kontrasta | 400:1 (Typ.) |
| boje prikaza | 262K (6-bit) |
| vrijeme odziva | 10/20 (Typ.)(Tr/Td) |
| kut gledanja | 70/70/60/50 (Typ.)(CR≥10)(L/R/U/D) |
| frekvencija | 60Hz |
| tip svjetiljke | 2 pcsCCFLEmbedded (Inverter) |
| signalno sučelje | Analog RGB + Composite Video (NTSC/PAL), 20 pins |
| ulazni napon | 13.8V (Typ.)(VCC) |
| primjena | CNS |
