| Broj dijela | LQ065T5AR05 |
| Marka | SHARP |
| Veličina | 6.5 |
| Primjena | CNS |
| Rezolucija | 400×234 |
| Sastav | LCM |
| Svjetlina | 420 |
| CR | 100:1 |
| Boje | Full color |
| Pozadinsko osvjetljenje | CCFL |
| Sučelje | Analog |
| marka panela | SHARP |
| panelni model | LQ065T5AR05 |
| vrsta panela | a-Si TFT-LCD , LCM |
| veličina ploče | 6.5 inch |
| rezolucija | 400(RGB)×234 |
| način prikaza | TN, Normally White, Transmissive |
| aktivno područje | 143.4×79.326 mm |
| obris | 155×89.2 mm |
| površinski | Antiglare, Antireflection |
| svjetlina | 420 cd/m² (Typ.) |
| omjer kontrasta | 100:1 (Typ.) |
| boje prikaza | Full color |
| vrijeme odziva | 30/50 (Typ.)(CR≥10) |
| kut gledanja | 50/50/35/55 (Typ.)(CR≥10)(L/R/U/D) |
| tip svjetiljke | 1 pcsCCFLEmbedded (Inverter) |
| signalno sučelje | Analog, 30 pins |
| ulazni napon | 12.0V (Typ.)(VIN) |
| primjena | CNS |
