| Broj dijela | LP154W01-TLAA |
| Marka | LG Display |
| Veličina | 15.4 |
| Primjena | NBPC |
| Rezolucija | 1280×800 |
| Sastav | LCM |
| Svjetlina | 170 |
| CR | 300:1 |
| Boje | 262K |
| Pozadinsko osvjetljenje | CCFL |
| Sučelje | LVDS |
| marka panela | LG.Philips LCD |
| panelni model | LP154W01-TLAA 7 Compatible model |
| vrsta panela | a-Si TFT-LCD , LCM |
| veličina ploče | 15.4 inch |
| rezolucija | 1280(RGB)×800 , WXGA |
| način prikaza | TN, Normally White, Transmissive |
| aktivno područje | 331.2×207 mm |
| stil oblika | Wedge (PCBA Bent, Depth ≥5.2mm) |
| površinski | Antiglare, Hard coating (3H) |
| svjetlina | 170 cd/m² (Typ.) |
| omjer kontrasta | 300:1 (Typ.) |
| boje prikaza | 262K (6-bit), CIE193145% |
| vrijeme odziva | 30 (Typ.)(Tr+Td) |
| kut gledanja | 40/40/10/30 (Min.)(CR≥10)(L/R/U/D) |
| frekvencija | 60Hz |
| tip svjetiljke | 1 pcsCCFLWithout Driver |
| signalno sučelje | LVDS (1 ch, 6-bit), 30 pins |
| ulazni napon | 3.3V (Typ.) |
| primjena | NBPC |
| LP154W01-TLA3 | LG Display | 15.4 | 1280×800 |
| LP154W01-TLAA | LG Display | 15.4 | 1280×800 |
| LP154W01-TLE5 | LG Display | 15.4 | 1280×800 |
| LP154W02-B1K2 | LG Display | 15.4 | 1680×1050 |
| LP154W02-B1K6 | LG Display | 15.4 | 1680×1050 |
| LP154WP2-TLA1 | LG Display | 15.4 | 1440×900 |
| LP154WP2-TLA2 | LG Display | 15.4 | 1440×900 |
| LP154WP2-TLC2 | LG Display | 15.4 | 1440×900 |
| LP154WP4-TLB1 | LG Display | 15.4 | 1440×900 |
| LP154WU1-TLA2 | LG Display | 15.4 | 1920×1200 |
| B140EW01 V1 | AUO | 14.0 | 1280×768 |
| B140RW03 V1 | AUO | 14.0 | 1600×900 |
| B141XG08 V3 | AUO | 14.1 | 1024×768 |
| CLAA154WB04A | CPT | 15.4 | 1280×800 |
| HT14P12-100 | HYDIS | 14.1 | 1400×1050 |
| LP133WQ1-SJEV | LG Display | 13.3 | 2560×1600 |
| LP133WX2-TLAA | LG Display | 13.3 | 1280×800 |
| LP133X3 | LG Display | 13.3 | 1024×768 |
| LTN154AT07-L01 | Samsung | 15.4 | 1280×800 |
| LTN173HT02-X01 | Samsung | 17.3 | 1920×1080 |
