| Broj dijela | B140RW03 V1 |
| Marka | AUO |
| Veličina | 14.0 |
| Primjena | NBPC |
| Rezolucija | 1600×900 |
| Sastav | LCM |
| Svjetlina | 300 |
| CR | 400:1 |
| Boje | 262K |
| Pozadinsko osvjetljenje | WLED |
| Sučelje | LVDS |
| marka panela | AUO |
| panelni model | B140RW03 V1 3 Compatible model |
| vrsta panela | a-Si TFT-LCD , LCM |
| veličina ploče | 14.0 inch |
| rezolucija | 1600(RGB)×900 , HD+ |
| način prikaza | TN, Normally White, Transmissive |
| aktivno područje | 309.6×174.15 mm |
| obris | 323.5×192.5×5.2 mm |
| stil oblika | Wedge (PCBA Bent, Depth ≥5.2mm) |
| površinski | Antiglare, Hard coating (3H) |
| svjetlina | 300 cd/m² (Typ.) |
| omjer kontrasta | 400:1 (Typ.) |
| boje prikaza | 262K (6-bit), CIE193145% |
| vrijeme odziva | 8 (Typ.)(Tr+Td) |
| kut gledanja | 45/45/15/35 (Typ.)(CR≥10)(L/R/U/D) |
| frekvencija | 60Hz |
| tip svjetiljke | WLEDEmbedded (LED Driver) |
| signalno sučelje | LVDS (2 ch, 6-bit), 40 pins |
| ulazni napon | 3.3V (Typ.) |
| primjena | NBPC |
| B140RTN01.0 | AUO | 14.0 | 1600×900 |
| B140RTN02.1 | AUO | 14.0 | 1600×900 |
| B140RTN02.3 | AUO | 14.0 | 1600×900 |
| B140RTN03.0 | AUO | 14.0 | 1600×900 |
| B140RW01 V0 | AUO | 14.0 | 1600×900 |
| B140RW01 V2 | AUO | 14.0 | 1600×900 |
| B140RW02 V0 | AUO | 14.0 | 1600×900 |
| B140RW02 V1 | AUO | 14.0 | 1600×900 |
| B140RW02 V2 | AUO | 14.0 | 1600×900 |
| B140RW03 V1 | AUO | 14.0 | 1600×900 |
| HN116WX1-100 | BOE | 11.6 | 1366×768 |
| HT14X13-102 | HYDIS | 14.1 | 1024×768 |
| LTD104EDZS | TOSHIBA | 10.4 | 1024×768 |
| LTN121XJ-L07 | Samsung | 12.1 | 1024×768 |
| LTN133AT27-102 | Samsung | 13.3 | 1366×768 |
| LTN141AT16-001 | Samsung | 14.1 | 1280×800 |
| LTN156AT35-H01 | Samsung | 15.6 | 1366×768 |
| N121IB-L04 | Innolux | 12.1 | 1280×800 |
| NL12876BC15-01 | NLT | 8.9 | 1280×768 |
| TM121XG-02L01 | SANYO | 12.1 | 1024×768 |
