| Broj dijela | NL12876BC15-01 |
| Marka | NLT |
| Veličina | 8.9 |
| Primjena | NBPC |
| Rezolucija | 1280×768 |
| Sastav | LCM |
| Svjetlina | 280 |
| CR | 500:1 |
| Boje | 262K |
| Pozadinsko osvjetljenje | WLED |
| Sučelje | LVDS |
| marka panela | NEC |
| panelni model | NL12876BC15-01 |
| vrsta panela | a-Si TFT-LCD , LCM |
| veličina ploče | 8.9 inch |
| rezolucija | 1280(RGB)×768 , WXGA |
| način prikaza | TN, Normally White, Transmissive |
| aktivno područje | 193.92×116.352 mm |
| obris | 209.2×130.3×7.7 mm |
| površinski | Clear, Hard coating (3H) |
| svjetlina | 280 cd/m² (Typ.) |
| omjer kontrasta | 500:1 (Typ.) |
| boje prikaza | 262K (6-bit), CIE193156% |
| vrijeme odziva | 6/2 (Typ.)(Tr/Td) |
| kut gledanja | 45/45/20/40 (Typ.)(CR≥10)(L/R/U/D) |
| frekvencija | 60Hz |
| tip svjetiljke | 11S3PWLEDWithout Driver |
| signalno sučelje | LVDS (1 ch, 6-bit), 30 pins |
| ulazni napon | 3.3V (Typ.) |
| primjena | NBPC |
