| Broj dijela | LP154WP2-TLC2 |
| Marka | LG Display |
| Veličina | 15.4 |
| Primjena | NBPC |
| Rezolucija | 1440×900 |
| Sastav | LCM |
| Svjetlina | 300 |
| CR | 600:1 |
| Boje | 262K |
| Pozadinsko osvjetljenje | WLED |
| Sučelje | LVDS |
| marka panela | LG Display |
| panelni model | LP154WP2-TLC2 3 Compatible model |
| vrsta panela | a-Si TFT-LCD , LCM |
| veličina ploče | 15.4 inch |
| rezolucija | 1440(RGB)×900 , WXGA+ |
| način prikaza | TN, Normally White, Transmissive |
| aktivno područje | 331.344×207.09 mm |
| obris | 344×222×6.1 mm |
| stil oblika | Wedge (PCBA Bent, Depth ≥5.2mm) |
| površinski | Glare (Haze 0%), Hard coating (3H) |
| svjetlina | 300 cd/m² (Typ.) |
| omjer kontrasta | 600:1 (Typ.) |
| boje prikaza | 262K (6-bit), CIE193145% |
| vrijeme odziva | 16 (Typ.)(Tr+Td) |
| kut gledanja | 70/70/55/65 (Typ.)(CR≥10)(L/R/U/D) |
| frekvencija | 60Hz |
| tip svjetiljke | 10S6PWLEDEmbedded (LED Driver) |
| signalno sučelje | LVDS (2 ch, 6-bit), 50 pins |
| ulazni napon | 3.3V (Typ.) |
| primjena | NBPC |
| LP154W01-A3 | LG Display | 15.4 | 1280×800 |
| LP154WE2-TLA3 | LG Display | 15.4 | 1680×1050 |
| LP154WE2-TLA8 | LG Display | 15.4 | 1680×1050 |
| LP154WE3-TLB1 | LG Display | 15.4 | 1680×1050 |
| LP154WP2-TLC2 | LG Display | 15.4 | 1440×900 |
| LP154WU1-TLB1 | LG Display | 15.4 | 1920×1200 |
| LP154WX4-TLC8 | LG Display | 15.4 | 1280×800 |
| LP154WX4-TLCB | LG Display | 15.4 | 1280×800 |
| LP154WX5-TLA1 | LG Display | 15.4 | 1280×800 |
| LP154WX7-TLP1 | LG Display | 15.4 | 1280×800 |
| B140XTN03.3 HW0A | AUO | 14.0 | 1366×768 |
| B156XW02 V3 | AUO | 15.6 | 1366×768 |
| CLAA154WA01 | CPT | 15.4 | 1280×800 |
| LP171WX2-TLA2 | LG Display | 17.1 | 1440×900 |
| LTN121AT10-301 | Samsung | 12.1 | 1280×800 |
| LTN121W1-L02 | Samsung | 12.1 | 1280×800 |
| LTN125AT03-803 | Samsung | 12.5 | 1366×768 |
| LTN141AT08-001 | Samsung | 14.1 | 1280×800 |
| LTN154X3-L09-G | Samsung | 15.4 | 1280×800 |
| N154C6-L04 | Innolux | 15.4 | 1440×900 |
