| Broj dijela | HT14P12-100 |
| Marka | HYDIS |
| Veličina | 14.1 |
| Primjena | NBPC |
| Rezolucija | 1400×1050 |
| Sastav | LCM |
| Svjetlina | 150 |
| CR | 200:1 |
| Boje | 262K |
| Pozadinsko osvjetljenje | CCFL |
| Sučelje | LVDS |
| marka panela | BOE HYDIS |
| panelni model | HT14P12-100 |
| vrsta panela | a-Si TFT-LCD , LCM |
| veličina ploče | 14.1 inch |
| rezolucija | 1400(RGB)×1050 , SXGA+ |
| način prikaza | TN, Normally White, Transmissive |
| aktivno područje | 285.6×214.2 mm |
| obris | 299×228×5.5 mm |
| stil oblika | Wedge (PCBA Bent, Depth ≥5.2mm) |
| površinski | |
| svjetlina | 150 cd/m² (Typ.) |
| omjer kontrasta | 200:1 (Min.) |
| boje prikaza | 262K (6-bit) |
| vrijeme odziva | 25/25 (Max.)(Tr/Td) |
| kut gledanja | 45/45/15/35 (Typ.)(CR≥10)(L/R/U/D) |
| frekvencija | 60Hz |
| tip svjetiljke | 1 pcsCCFLWithout Driver |
| signalno sučelje | LVDS (2 ch, 6-bit), 30 pins |
| ulazni napon | 3.3V (Typ.) |
| primjena | NBPC |
