| Broj dijela | HV056WX1-100 |
| Marka | HYDIS |
| Veličina | 5.6 |
| Primjena | UMPC |
| Rezolucija | 1280×800 |
| Sastav | LCM |
| Svjetlina | 300 |
| CR | 500:1 |
| Boje | 262K |
| Pozadinsko osvjetljenje | WLED |
| Sučelje | LVDS |
| marka panela | BOE HYDIS |
| panelni model | HV056WX1-100 |
| vrsta panela | a-Si TFT-LCD , LCM |
| veličina ploče | 5.6 inch |
| rezolucija | 1280(RGB)×800 , WXGA |
| način prikaza | HFFS, Normally Black, Transmissive |
| aktivno područje | 120.96×75.6 mm |
| obris | 131.7×87.7×5 mm |
| površinski | |
| svjetlina | 300 cd/m² (Typ.) |
| omjer kontrasta | 500:1 (Typ.) |
| boje prikaza | 262K (6-bit) |
| vrijeme odziva | 30 (Typ.)(Tr+Td) |
| kut gledanja | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| frekvencija | 60Hz |
| tip svjetiljke | 8S2PWLEDEmbedded (LED Driver) |
| signalno sučelje | LVDS (1 ch, 6-bit), 25 pins |
| ulazni napon | 3.3V (Typ.) |
| primjena | UMPC |
| AT056TN52 V.2 | Innolux | 5.6 | 640×480 |
| AT056TN52 V.4 | Innolux | 5.6 | 640×480 |
| HV056WX1-100 | HYDIS | 5.6 | 1280×800 |
| HV056WX1-101 | HYDIS | 5.6 | 1280×800 |
| HV056WX2-100 | HYDIS | 5.6 | 1280×800 |
| LQ056A3AG01 | SHARP | 5.6 | 320×234 |
| LQ056A3AG01R | SHARP | 5.6 | 320×234 |
| LQ056A5GG01 | SHARP | 5.6 | 320×234 |
| LTD056ET0T | TOSHIBA | 5.6 | 1024×600 |
| LTD056EV7F00 | TOSHIBA | 5.6 | 1280×800 |
| ACX534AKM-2 | SONY | 5.0 | 800×600 |
| CLAA070NP01 | CPT | 7.0 | 1024×600 |
| HJ070IA-02F | Innolux | 7.0 | 1280×800 |
| HSD070PWW1-C00 | HannStar | 7.0 | 1280×800 |
| LB048WV1-TL01 | LG Display | 4.8 | 800×480 |
| LD070WS2-SL01 | LG Display | 7.0 | 1024×600 |
| LQ050W1LA0A | SHARP | 5.0 | 1024×600 |
| LT080EE04000 | TOSHIBA | 8.0 | 1600×768 |
| N070ICG-LD1 | Innolux | 7.0 | 1280×800 |
| N070ICG-LD4 | Innolux | 7.0 | 1280×800 |
