| Broj dijela | LB048WV1-TL01 |
| Marka | LG Display |
| Veličina | 4.8 |
| Primjena | UMPC |
| Rezolucija | 800×480 |
| Sastav | LCM |
| Svjetlina | 280 |
| CR | 350:1 |
| Boje | 262K |
| Pozadinsko osvjetljenje | WLED |
| Sučelje | LVDS |
| marka panela | LG.Philips LCD |
| panelni model | LB048WV1-TL01 |
| vrsta panela | a-Si TFT-LCD , LCM |
| veličina ploče | 4.8 inch |
| rezolucija | 800(RGB)×480 , WVGA |
| način prikaza | TN, Normally White, Transmissive |
| aktivno područje | 103.8×62.28 mm |
| obris | 114.65×74.7×5.88 mm |
| površinski | Glare (Haze 0%), Hard coating (3H) |
| svjetlina | 280 cd/m² (Typ.) |
| omjer kontrasta | 350:1 (Typ.) |
| boje prikaza | 262K (6-bit) |
| vrijeme odziva | 16 (Typ.)(Tr+Td) |
| kut gledanja | 65/65/50/50 (Typ.)(CR≥10)(L/R/U/D) |
| frekvencija | 60Hz |
| tip svjetiljke | 6S2PWLEDEmbedded (LED Driver) |
| signalno sučelje | LVDS (1 ch, 6-bit), 30 pins |
| ulazni napon | 3.3V (Typ.) |
| primjena | UMPC |
