| Broj dijela | LQ056A3AG01 |
| Marka | SHARP |
| Veličina | 5.6 |
| Primjena | |
| Rezolucija | 320×234 |
| Sastav | LCM |
| Svjetlina | 250 |
| CR | 60:1 |
| Boje | Full color |
| Pozadinsko osvjetljenje | CCFL |
| Sučelje | Analog |
| marka panela | SHARP |
| panelni model | LQ056A3AG01 |
| vrsta panela | a-Si TFT-LCD , LCM |
| veličina ploče | 5.6 inch |
| rezolucija | 320(RGB)×234 |
| način prikaza | TN, Normally White, Transmissive |
| aktivno područje | 114.2×83.5 mm |
| obris | 140×102.7 mm |
| površinski | |
| svjetlina | 250 cd/m² (Typ.) |
| omjer kontrasta | 60:1 (Min.) |
| boje prikaza | Full color |
| vrijeme odziva | 15/20 (Typ.)(Tr/Td) |
| kut gledanja | 65/65/40/65 (Typ.)(CR≥5)(L/R/U/D) |
| tip svjetiljke | 1 pcsCCFLEmbedded (Inverter) |
| signalno sučelje | Analog RGB + Composite Video (NTSC/PAL), 24 pins |
| ulazni napon | 12.0V (Typ.) |
