| Broj dijela | HT10X21-311 |
| Marka | HYDIS |
| Veličina | 10.4 |
| Primjena | PAD |
| Rezolucija | 1024×768 |
| Sastav | LCM |
| Svjetlina | 170 |
| CR | 500:1 |
| Boje | 262K |
| Pozadinsko osvjetljenje | CCFL |
| Sučelje | LVDS |
| marka panela | BOE HYDIS |
| panelni model | HT10X21-311 |
| vrsta panela | a-Si TFT-LCD , LCM |
| veličina ploče | 10.4 inch |
| rezolucija | 1024(RGB)×768 , XGA |
| način prikaza | FFS, Normally Black, Transmissive |
| aktivno područje | 210.4×157.8 mm |
| obris | 238.6×173.2 mm |
| površinski | Antiglare (Haze 25%), Hard coating (3H) |
| svjetlina | 170 cd/m² (Typ.) |
| omjer kontrasta | 500:1 (Typ.) |
| boje prikaza | 262K (6-bit), CIE193145% |
| vrijeme odziva | 40 (Typ.)(Tr+Td) |
| kut gledanja | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| frekvencija | 60Hz |
| tip svjetiljke | 1 pcsCCFLWithout Driver |
| signalno sučelje | LVDS (1 ch, 6-bit), 14 pins |
| ulazni napon | 3.3V (Typ.) |
| primjena | PAD |
