| Broj dijela | G104XGE-L05 |
| Marka | Innolux |
| Veličina | 10.4 |
| Primjena | IA |
| Rezolucija | 1024×768 |
| Sastav | LCM |
| Svjetlina | 500 |
| CR | 1200:1 |
| Boje | 262K/16.2M |
| Pozadinsko osvjetljenje | WLED |
| Sučelje | LVDS |
| marka panela | CHIMEI INNOLUX |
| panelni model | G104XGE-L05 |
| vrsta panela | a-Si TFT-LCD , LCM |
| veličina ploče | 10.4 inch |
| rezolucija | 1024(RGB)×768 , XGA |
| način prikaza | Super MVA, Normally Black, Transmissive |
| aktivno područje | 210.4×157.8 mm |
| obris | 225.5×176.3×9.2 mm |
| površinski | Glare (Haze 0%), Hard coating (3H) |
| svjetlina | 500 cd/m² (Typ.) |
| omjer kontrasta | 1200:1 (Typ.) |
| boje prikaza | 262K/16.2M (6-bit / 6-bit + FRC), CIE193155% |
| vrijeme odziva | 25 (Typ.)(Tr+Td) |
| kut gledanja | 88/88/88/88 (Typ.)(CR≥10)(L/R/U/D) |
| frekvencija | 60Hz |
| tip svjetiljke | WLEDEmbedded (LED Driver) |
| signalno sučelje | LVDS (1 ch, 6/8-bit), 30 pins |
| ulazni napon | 3.3V (Typ.) |
| primjena | IA |
| G104X1-L01 | Innolux | 10.4 | 1024×768 |
| G104X1-L02 | Innolux | 10.4 | 1024×768 |
| G104X1-L03 | Innolux | 10.4 | 1024×768 |
| G104X1-L04 | Innolux | 10.4 | 1024×768 |
| G104XGE-L05 | Innolux | 10.4 | 1024×768 |
| G104XVN01.0 | AUO | 10.4 | 1024×768 |
| LM-CC53-22NDK | SANYO | 10.4 | 640×480 |
| LP104S2 | LG Display | 10.4 | 800×600 |
| LQ104S1LG61 | SHARP | 10.4 | 800×600 |
| LTD104C11Z | TOSHIBA | 10.4 | 640×480 |
| DMF-50840NB-FW | Kyocera | 5.7 | 320×240 |
| EG4401S-ER | Epson | 5.3 | 256×128 |
| G084SN03 V2 | AUO | 8.4 | 800×600 |
| G104SN03 V5 | AUO | 10.4 | 800×600 |
| G190SF01 V0 | AUO | 19.0 | 1680×342 |
| LM270WQ1-SLC2 | LG Display | 27.0 | 2560×1440 |
| LQ057V3LG11 | SHARP | 5.7 | 640×480 |
| NL6448AC33-29 | NLT | 10.4 | 640×480 |
| NL8060BC21-03 | NLT | 8.4 | 800×600 |
| TFD60W20MS | TOSHIBA | 6.0 | 320×240 |
