| Broj dijela | HSD101PUW1-A00 |
| Marka | HannStar |
| Veličina | 10.1 |
| Primjena | PAD |
| Rezolucija | 1920×1200 |
| Sastav | LCM |
| Svjetlina | 380 |
| CR | 1000:1 |
| Boje | 16.7M |
| Pozadinsko osvjetljenje | WLED |
| Sučelje | MIPI |
| marka panela | HannStar |
| panelni model | HSD101PUW1-A00 |
| vrsta panela | a-Si TFT-LCD , LCM |
| veličina ploče | 10.1 inch |
| rezolucija | 1920(RGB)×1200 , WUXGA |
| način prikaza | HS-IPS, Normally Black, Transmissive |
| aktivno područje | 216.576×135.36 mm |
| obris | 227.72×147.8×4.55 mm |
| površinski | Hard coating |
| svjetlina | 380 cd/m² (Typ.) |
| omjer kontrasta | 1000:1 (Typ.) |
| boje prikaza | 16.7M (6-bit + Hi-FRC), CIE193150% |
| vrijeme odziva | 25 (Typ.)(Tr+Td) |
| kut gledanja | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| frekvencija | 60Hz |
| tip svjetiljke | WLEDEmbedded (LED Driver) |
| signalno sučelje | MIPI (4 data lanes), 34 pins |
| ulazni napon | 3.3V (Typ.) |
| primjena | PAD |
