| Broj dijela | LTL106HL01-001 |
| Marka | Samsung |
| Veličina | 10.6 |
| Primjena | PAD |
| Rezolucija | 1920×1080 |
| Sastav | LCM |
| Svjetlina | 400 |
| CR | 800:1 |
| Boje | 16.7M |
| Pozadinsko osvjetljenje | WLED |
| Sučelje | LVDS |
| marka panela | SAMSUNG |
| panelni model | LTL106HL01-001 |
| vrsta panela | a-Si TFT-LCD , LCM |
| veličina ploče | 10.6 inch |
| rezolucija | 1920(RGB)×1080 , FHD |
| način prikaza | PLS, Normally Black, Transmissive |
| aktivno područje | 234.72×132.03 mm |
| obris | 246.52×149.02×5.2 mm |
| površinski | Glare (Haze 0%), Hard coating (2H) |
| svjetlina | 400 cd/m² (Typ.) |
| omjer kontrasta | 800:1 (Typ.) |
| boje prikaza | 16.7M (8-bit), CIE193150% |
| vrijeme odziva | 16 (Typ.)(Tr+Td) |
| kut gledanja | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| frekvencija | 60Hz |
| tip svjetiljke | 9S4PWLEDEmbedded (LED Driver) |
| signalno sučelje | LVDS (2 ch, 8-bit), 51 pins |
| ulazni napon | 3.3V (Typ.) |
| primjena | PAD |
