| Broj dijela | G170J1-LE1 |
| Marka | Innolux |
| Veličina | 17.0 |
| Primjena | IA |
| Rezolucija | 1920×1200 |
| Sastav | LCM |
| Svjetlina | 600 |
| CR | 2000:1 |
| Boje | 16.7M |
| Pozadinsko osvjetljenje | WLED |
| Sučelje | LVDS |
| marka panela | INNOLUX |
| panelni model | G170J1-LE1 |
| vrsta panela | a-Si TFT-LCD , LCM |
| veličina ploče | 17.0 inch |
| rezolucija | 1920(RGB)×1200 , WUXGA |
| način prikaza | Super MVA, Normally Black, Transmissive |
| aktivno područje | 365.76×228.6 mm |
| obris | 386.8×250.8×19 mm |
| površinski | Glare (Haze 0%) |
| svjetlina | 600 cd/m² (Typ.) |
| omjer kontrasta | 2000:1 (Typ.) |
| boje prikaza | 16.7M (8-bit), CIE193170% |
| vrijeme odziva | 20/9 (Typ.)(Tr/Td) |
| kut gledanja | 88/88/88/88 (Typ.)(CR≥10)(L/R/U/D) |
| frekvencija | 60Hz |
| tip svjetiljke | WLEDEmbedded (LED Driver) |
| signalno sučelje | LVDS (2 ch, 8-bit), 30 pins |
| ulazni napon | 5.0V (Typ.) |
| primjena | IA |
