| Broj dijela | CLAA069LA0NCW |
| Marka | CPT |
| Veličina | 7.0 |
| Primjena | CNS |
| Rezolucija | 800×480 |
| Sastav | LCM |
| Svjetlina | 500 |
| CR | 400:1 |
| Boje | 262K |
| Pozadinsko osvjetljenje | WLED |
| Sučelje | TTL |
| marka panela | CPT |
| panelni model | CLAA069LA0NCW |
| vrsta panela | a-Si TFT-LCD , LCM |
| veličina ploče | 7.0 inch |
| rezolucija | 800(RGB)×480 , WVGA |
| način prikaza | TN, Normally White, Transmissive |
| aktivno područje | 156.6×81.6 mm |
| obris | 167×93×6.47 mm |
| površinski | Antiglare, Hard coating (3H) |
| svjetlina | 500 cd/m² (Typ.) |
| omjer kontrasta | 400:1 (Typ.) |
| boje prikaza | 262K (6-bit) |
| vrijeme odziva | 20 (Typ.)(Tr+Td) |
| kut gledanja | 70/70/50/70 (Typ.)(CR≥10)(L/R/U/D) |
| frekvencija | 60Hz |
| tip svjetiljke | 9S3PWLEDWithout Driver |
| signalno sučelje | TTL (1 ch, 6-bit), 50 pins |
| ulazni napon | 3.3/9.2/18/-6V (Typ.)(DVDD/AVDD/VDDG/VEEG) |
| primjena | CNS |
| CLAA061LA0DCW | CPT | 6.1 | 800×480 |
| CLAA062LA01CW | CPT | 6.2 | 800×480 |
| CLAA069JA11CW | CPT | 7.0 | 480×234 |
| CLAA069LA0ACW | CPT | 7.0 | 800×480 |
| CLAA069LA0NCW | CPT | 7.0 | 800×480 |
| CLAA069LA1AAW | CPT | 7.0 | 800×480 |
| CLAA069LB02CW | CPT | 7.0 | 800×480 |
| CLAA069LB03CW | CPT | 7.0 | 800×480 |
| CLAA069LB06 CW | CPT | 7.0 | 800×480 |
| CLAA069LC01XW | CPT | 7.0 | 800×480 |
| AT070TN94 | Innolux | 7.0 | 800×480 |
| CLAA080LJ01CW | CPT | 8.0 | 800×480 |
| G150X1-L01 | Innolux | 15.0 | 1024×768 |
| LA070WV4-SD04 | LG Display | 7.0 | 800×480 |
| LA080WV1-TD01 | LG Display | 8.0 | 800×480 |
| LB058WQ1-SD02 | LG Display | 5.8 | 400×240 |
| LQ050Q5DR01 | SHARP | 5.0 | 320×240 |
| LT050CA41000 | JDI | 5.0 | 800×480 |
| TJ123NP01AA | TPO | 12.3 | 1280×480 |
| YX050800480WTIPS | 5.0 | 800×480 |
