| Broj dijela | BI097XN02 V.Y |
| Marka | Innolux |
| Veličina | 9.7 |
| Primjena | |
| Rezolucija | 1024×768 |
| Sastav | LCM |
| Svjetlina | 350 |
| CR | 800:1 |
| Boje | 262K |
| Pozadinsko osvjetljenje | WLED |
| Sučelje | LVDS |
| marka panela | CHIMEI INNOLUX |
| panelni model | BI097XN02 V.Y |
| vrsta panela | a-Si TFT-LCD , LCM |
| veličina ploče | 9.7 inch |
| rezolucija | 1024(RGB)×768 , XGA |
| način prikaza | IPS, Normally Black, Transmissive |
| aktivno područje | 196.608×147.456 mm |
| obris | 210×164.25×5.65 mm |
| površinski | |
| svjetlina | 350 cd/m² (Typ.) |
| omjer kontrasta | 800:1 (Typ.) |
| boje prikaza | 262K (6-bit), CIE193150% |
| vrijeme odziva | 25 (Typ.)(Tr+Td) |
| kut gledanja | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| frekvencija | 60Hz |
| tip svjetiljke | 6 stringsWLEDWithout Driver |
| signalno sučelje | LVDS (1 ch, 6-bit), 30 pins |
| ulazni napon | 3.3V (Typ.) |
