| Broj dijela | LP097QX2-SPAV |
| Marka | LG Display |
| Veličina | 9.7 |
| Primjena | PAD |
| Rezolucija | 1536×2048 |
| Sastav | LCM |
| Svjetlina | 440 |
| CR | 800:1 |
| Boje | 16.7M |
| Pozadinsko osvjetljenje | WLED |
| Sučelje | eDP |
| marka panela | LG Display |
| panelni model | LP097QX2-SPAV |
| vrsta panela | a-Si TFT-LCD , LCM |
| veličina ploče | 9.7 inch |
| rezolucija | 1536(RGB)×2048 , QXGA |
| način prikaza | IPS, Normally Black, Transmissive |
| aktivno područje | 147.456×196.608 mm |
| obris | 160.3×208.93 mm |
| površinski | Glare (Haze 0%), Hard coating (3H), Antireflection |
| svjetlina | 440 cd/m² (Typ.) |
| omjer kontrasta | 800:1 (Typ.) |
| boje prikaza | 16.7M (8-bit) |
| vrijeme odziva | 30 (Typ.)(Tr+Td) |
| kut gledanja | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| frekvencija | 60Hz |
| tip svjetiljke | WLEDWithout Driver |
| signalno sučelje | eDP (4 Lanes), 42 pins |
| ulazni napon | 3.7V (Typ.) |
| primjena | PAD |
