| Broj dijela | TD036THEA1 |
| Marka | TPO |
| Veličina | 3.6 |
| Primjena | |
| Rezolucija | 320×240 |
| Sastav | LCM |
| Svjetlina | 280 |
| CR | 300:1 |
| Boje | 16.7M |
| Pozadinsko osvjetljenje | WLED |
| Sučelje | Serial RGB |
| marka panela | Toppoly |
| panelni model | TD036THEA1 |
| vrsta panela | LTPS TFT-LCD , LCM |
| veličina ploče | 3.6 inch |
| rezolucija | 320(RGB)×240 , QVGA |
| način prikaza | TN, Normally White, Transmissive |
| aktivno područje | 72.96×54.72 mm |
| obris | 80.2×66.3 mm |
| površinski | Hard coating (3H) |
| svjetlina | 280 cd/m² (Typ.) |
| omjer kontrasta | 300:1 (Typ.) |
| boje prikaza | 16.7M (8-bit) |
| vrijeme odziva | 13/22 (Typ.)(Tr/Td) |
| kut gledanja | 50/20/40/40 (Typ.)(CR≥10)(L/R/U/D) |
| tip svjetiljke | 3S2PWLED |
| signalno sučelje | Serial RGB (8-bit) + SPI, CCIR601, 39 pins |
| rohs: |
