| Broj dijela | AM-1024600KTMQW-04H |
| Marka | AMPIRE |
| Veličina | 7.0 |
| Primjena | CNS |
| Rezolucija | 1024×600 |
| Sastav | LCM |
| Svjetlina | 1000 |
| CR | 700:1 |
| Boje | 16.7M |
| Pozadinsko osvjetljenje | WLED |
| Sučelje | LVDS |
| marka panela | AMPIRE |
| panelni model | AM-1024600KTMQW-04H |
| vrsta panela | a-Si TFT-LCD , LCM |
| veličina ploče | 7.0 inch |
| rezolucija | 1024(RGB)×600 , WSVGA |
| način prikaza | TN, Normally White, Transmissive |
| aktivno područje | 153.6×90 mm |
| obris | 165.5×104.44×5.3 mm |
| površinski | Glare (Haze 0%), Hard coating |
| svjetlina | 1000 cd/m² (Typ.) |
| omjer kontrasta | 700:1 (Typ.) |
| boje prikaza | 16.7M (8-bit) |
| vrijeme odziva | 10/15 (Typ.)(Tr/Td) |
| kut gledanja | 75/75/75/75 (Typ.)(CR≥10)(L/R/U/D) |
| frekvencija | 60Hz |
| tip svjetiljke | 8S3PWLEDWithout Driver |
| signalno sučelje | LVDS (1 ch, 8-bit), 39 pins |
| ulazni napon | 3.3V (Typ.) |
| primjena | CNS |
| AM-1024600-070H | Other | 7.0 | 1024×600 |
| AM-1024600KTMQW-01H | AMPIRE | 7.0 | 1024×600 |
| AM-1024600KTMQW-04H | AMPIRE | 7.0 | 1024×600 |
| AM-1024600L3TMQW-T05H | AMPIRE | 10.1 | 1024×600 |
| AM-1024600L7TMQW-T05H | AMPIRE | 10.1 | 1024×600 |
| BA070WS1-400 | BOE | 7.0 | 1024×600 |
| CLAA070WP06 XG | CPT | 7.0 | 800×1280 |
| HJ070IA-02F | Innolux | 7.0 | 1280×800 |
| LQ070Y3LG05 | SHARP | 7.0 | 800×480 |
| N070Y1-T01 | Innolux | 7.0 | 800×480 |
| 70WVW1A | SII | 7.0 | 800×480 |
| A070VW01 V1 | AUO | 7.0 | 800×480 |
| AT062TN12 | Innolux | 6.2 | |
| C070VW04 V6 | AUO | 7.0 | 800×480 |
| CLAA070LFB1 CW | CPT | 7.0 | 800×480 |
| G121X1-L03 | Innolux | 12.1 | 1024×768 |
| LB070WV7-TL01 | LG Display | 7.0 | 800×480 |
| LQ058T5BA01 | SHARP | 5.8 | |
| NL3224AC35-01 | NLT | 5.5 | 320×240 |
| YX070DK02 | SEBO | 7.0 | 800×480 |
