| Broj dijela | AM-1024600KTMQW-01H |
| Marka | AMPIRE |
| Veličina | 7.0 |
| Primjena | IA |
| Rezolucija | 1024×600 |
| Sastav | LCM |
| Svjetlina | 1000 |
| CR | 700:1 |
| Boje | 16.7M |
| Pozadinsko osvjetljenje | WLED |
| Sučelje | LVDS |
| marka panela | AMPIRE |
| panelni model | AM-1024600KTMQW-01H |
| vrsta panela | a-Si TFT-LCD , LCM |
| veličina ploče | 7.0 inch |
| rezolucija | 1024(RGB)×600 , WSVGA |
| način prikaza | TN, Normally White, Transmissive |
| aktivno područje | 153.6×90 mm |
| obris | 165.5×104.44×7.91 mm |
| površinski | Glare (Haze 0%), Hard coating |
| svjetlina | 1000 cd/m² (Typ.) |
| omjer kontrasta | 700:1 (Typ.) |
| boje prikaza | 16.7M (8-bit) |
| vrijeme odziva | 10/15 (Typ.)(Tr/Td) |
| kut gledanja | 75/75/70/75 (Typ.)(CR≥10)(L/R/U/D) |
| frekvencija | 60Hz |
| tip svjetiljke | 8S3PWLEDEmbedded (LED Driver) |
| signalno sučelje | LVDS (1 ch, 8-bit), 20 pins |
| ulazni napon | 3.3V (Typ.) |
| primjena | IA |
