| Broj dijela | A035VL01 V3 |
| Marka | AUO |
| Veličina | 3.5 |
| Primjena | DVC |
| Rezolucija | 800×480 |
| Sastav | LCM |
| Svjetlina | 315 |
| CR | 800:1 |
| Boje | 16.7M |
| Pozadinsko osvjetljenje | WLED |
| Sučelje | TTL |
| marka panela | AUO |
| panelni model | A035VL01 V3 |
| vrsta panela | LTPS TFT-LCD , LCM |
| veličina ploče | 3.5 inch |
| rezolucija | 800(RGB)×480 , WVGA |
| način prikaza | TN, Normally White, Transmissive |
| aktivno područje | 75.6×45.36 mm |
| obris | 86.1×51.66 mm |
| površinski | Glare (Haze 0%) |
| svjetlina | 315 cd/m² (Typ.) |
| omjer kontrasta | 800:1 (Typ.) |
| boje prikaza | 16.7M (8-bit) |
| vrijeme odziva | 15/30 (Typ.)(Tr/Td) |
| kut gledanja | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| frekvencija | 60Hz |
| tip svjetiljke | WLEDWithout Driver |
| signalno sučelje | Parallel RGB (1 ch, 8-bit) + SPI, 70 pins |
| ulazni napon | 3.3/3.3V (Typ.)(VDD/VDDIO) |
| primjena | DVC |
