| Broj dijela | 990000475 |
| Marka | TPO |
| Veličina | 4.3 |
| Primjena | PND |
| Rezolucija | 800×480 |
| Sastav | LCM |
| Svjetlina | 300 |
| CR | 400:1 |
| Boje | 16.7M |
| Pozadinsko osvjetljenje | WLED |
| Sučelje | TTL |
| marka panela | TPO |
| panelni model | 990000475 |
| vrsta panela | LTPS TFT-LCD , LCM |
| veličina ploče | 4.3 inch |
| rezolucija | 800(RGB)×480 , WVGA |
| način prikaza | Normally Black, Transmissive |
| aktivno područje | 93.6×56.16 mm |
| obris | 100.6×68.45 mm |
| površinski | |
| svjetlina | 300 cd/m² (Typ.) |
| omjer kontrasta | 400:1 (Typ.) |
| boje prikaza | 16.7M (8-bit) |
| vrijeme odziva | 30/10 (Typ.)(Tr/Td) |
| kut gledanja | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| tip svjetiljke | 8S1PWLEDWithout Driver |
| signalno sučelje | Parallel RGB (1 ch, 8-bit) + SPI, 60 pins |
| ulazni napon | 3.3/5/-5V (Typ.)(VCC/AVDP/AVDN) |
| primjena | PND |
| 990000006 | TPO | 3.0 | 320×240 |
| 990000270 | TPO | 2.5 | 320×240 |
| 990000475 | TPO | 4.3 | 800×480 |
| 990000475P | TPO | 4.3 | 800×480 |
| 990000553 | TPO | 3.5 | 320×240 |
| 990000738 | TPO | 3.5 | 320×240 |
| 990000738A | Innolux | 3.5 | 320×240 |
| 990000881 | TPO | 3.0 | 960×480(dot) |
| 990001086 | Innolux | 3.0 | |
| DLC0430NZG | Other | 4.3 | 480×272 |
| 43WQW3T | SII | 4.3 | 480×272 |
| 43WVF0H | SII | 4.3 | 800×480 |
| A050FW02 V5 | AUO | 5.0 | 480×272 |
| AT050TN33 | Innolux | 5.0 | 480×272 |
| CLAA050LA0ACW | CPT | 5.0 | 800×480 |
| EJ050NA-01G | Innolux | 5.0 | 800×480 |
| LQ043T3DX04 | SHARP | 4.3 | 480×272 |
| P0430WQLC-T | CMEL | 4.3 | 480×272 |
| PT035TN01 V.3 | Innolux | 3.5 | 320×240 |
| TM047NBH01 | Tianma | 4.7 | 480×272 |
