| Broj dijela | WEF012864QS |
| Marka | Winstar |
| Veličina | 2.7 |
| Primjena | Home Appliance Handh |
| Rezolucija | 128×64 |
| Sastav | PM-OLED , OLED |
| Svjetlina | |
| CR | |
| Boje | Mono(Blue) |
| Pozadinsko osvjetljenje | self |
| Sučelje | 8-bit |
| marka panela | Winstar |
| veličina ploče | 2.7" |
| rezolucija | 128×64, 52PPI |
| područje prikaza | 61.41(W)×30.69(H) mm |
| veličina obrisa | 89.7(W)×47.2(H) mm |
| kut gledanja | - |
| najbolji pogled na | Symmetry |
| boje prikaza | Mono(Blue) |
| frekvencija | - |
| vozač ic | COG Built-in SSD1309ZC |
| težina panela | - |
| signalno sučelje | 8-bit 6800/8080 parallel, 4-wire SPI, I²C , 30 pins FPC |
| ulazni napon | 3.0/13V (Typ.)(VDD/VCC) |
| okoliš | Operating Temp.: -40 ~ 80 °C ; Storage Temp.: -40 ~ 80 °C |
| panelni model | WEF012864QS |
| vrsta panela | PM-OLED , OLED |
| format piksela | Rectangle |
| otvor za okvir | 63.41(W)×32.69(H) mm |
| površinski | - |
| način prikaza | - |
| vrijeme odziva | - |
| tip svjetiljke | self |
| ekran na dodir | Without |
| primjena | Home Appliance Handheld & PDA Healthcare Instruments & Meters |
