| Broj dijela | WEA012864DLPP3N00001 |
| Marka | Winstar |
| Veličina | 0.96 |
| Primjena | Instruments & Me |
| Rezolucija | 128×64 |
| Sastav | PM-OLED, OLED |
| Svjetlina | |
| CR | |
| Boje | Mono(Yellow) |
| Pozadinsko osvjetljenje | self |
| Sučelje | 4-wire |
| marka panela | Winstar |
| panelni model | WEA012864DLPP3N00001 |
| veličina ploče | 0.96" |
| vrsta panela | PM-OLED, OLED |
| rezolucija | 128×64, 149PPI |
| format piksela | Rectangle |
| područje prikaza | 21.74(W)×10.86(H) mm |
| otvor za okvir | 23.94(W)×12.06(H) mm |
| veličina obrisa | 38(W)×28.5(H) ×4.37(D) mm |
| površinski | - |
| kut gledanja | - |
| način prikaza | - |
| najbolji pogled na | Symmetry |
| vrijeme odziva | - |
| boje prikaza | Mono(Yellow) |
| tip svjetiljke | self |
| frekvencija | - |
| ekran na dodir | Without |
| vozač ic | COG Built-in SSD1306BZ |
| težina panela | - |
| primjena | Instruments & Meters |
| signalno sučelje | 4-wire SPI, I²C , 8 pins PIN |
| ulazni napon | 3.3/5.0/7.5V (Typ.) |
| okoliš | Operating Temp.: -40 ~ 80 °C ; Storage Temp.: -40 ~ 85 °C |
