| Broj dijela | TX18D41VM0EAA |
| Marka | KOE |
| Veličina | 7.0 |
| Primjena | IA |
| Rezolucija | 1024×600 |
| Sastav | LCM |
| Svjetlina | 400 |
| CR | 800:1 |
| Boje | 16.7M |
| Pozadinsko osvjetljenje | WLED |
| Sučelje | LVDS |
| marka panela | HITACHI |
| panelni model | TX18D41VM0EAA |
| vrsta panela | a-Si TFT-LCD , LCM |
| veličina ploče | 7.0 inch |
| rezolucija | 1024(RGB)×600 , WSVGA |
| način prikaza | IPS, Normally Black, Transmissive |
| aktivno područje | 153.6×90 mm |
| obris | 162.8×103.1×4.5 mm |
| površinski | |
| svjetlina | 400 cd/m² (Typ.) |
| omjer kontrasta | 800:1 (Typ.) |
| boje prikaza | 16.7M (8-bit), CIE193150% |
| vrijeme odziva | 35 (Typ.)(Tr+Td) |
| kut gledanja | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| frekvencija | 60Hz |
| tip svjetiljke | 7S3PWLEDWithout Driver |
| signalno sučelje | LVDS (1 ch, 8-bit) + SPI, 30 pins |
| ulazni napon | 3.3V (Typ.) |
| primjena | IA |
