| Broj dijela | LM12S49 |
| Marka | SHARP |
| Veličina | 12.1 |
| Primjena | IA |
| Rezolucija | 800×600 |
| Sastav | LCM |
| Svjetlina | 185 |
| CR | 40:1 |
| Boje | Color |
| Pozadinsko osvjetljenje | CCFL |
| Sučelje | TTL |
| marka panela | SHARP |
| panelni model | LM12S49 |
| vrsta panela | CSTN-LCD , LCM |
| veličina ploče | 12.1 inch |
| rezolucija | 800(RGB)×600 , SVGA |
| način prikaza | STN, Normally Black, Transmissive |
| aktivno područje | 246×184.5 mm |
| obris | 275×202.5×8.5 mm |
| površinski | |
| svjetlina | 185 cd/m² (Typ.) |
| omjer kontrasta | 40:1 (Typ.) |
| boje prikaza | Color |
| vrijeme odziva | 220/80 (Typ.)(Tr/Td) |
| kut gledanja | 30/30/15/25 (Typ.)(CR≥5)(L/R/U/D) |
| frekvencija | 120Hz |
| tip svjetiljke | 2 pcsCCFLWithout Driver |
| signalno sučelje | CMOS/TTL (1 ch, 8-bit), 41 pins |
| ulazni napon | 3.3/5.0V (Typ.)(VDD) |
| primjena | IA |
