| Broj dijela | TX18D35VM0AAA |
| Marka | KOE |
| Veličina | 7.0 |
| Primjena | CNS |
| Rezolucija | 800×480 |
| Sastav | LCM |
| Svjetlina | 450 |
| CR | 600:1 |
| Boje | 262K |
| Pozadinsko osvjetljenje | WLED |
| Sučelje | TTL |
| marka panela | HITACHI |
| panelni model | TX18D35VM0AAA |
| vrsta panela | a-Si TFT-LCD , LCM |
| veličina ploče | 7.0 inch |
| rezolucija | 800(RGB)×480 , WVGA |
| način prikaza | IPS Pro, Normally Black, Transmissive |
| aktivno područje | 152.4×91.44 mm |
| obris | 165×104×13.3 mm |
| površinski | |
| svjetlina | 450 cd/m² (Typ.) |
| omjer kontrasta | 600:1 (Typ.) |
| boje prikaza | 262K (6-bit) |
| vrijeme odziva | 45 (Max.)(Tr+Td) |
| kut gledanja | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| frekvencija | 60Hz |
| tip svjetiljke | 3S4PWLEDEmbedded (LED Driver) |
| signalno sučelje | CMOS (1 ch, 6-bit), 40 pins |
| ulazni napon | 3.3V (Typ.)(VDD) |
| primjena | CNS |
