| Broj dijela | TM320240EGFWVSWD |
| Marka | Tianma |
| Veličina | 5.7 |
| Primjena | IA |
| Rezolucija | 320×240 |
| Sastav | LCM |
| Svjetlina | 60 |
| CR | 8:1 |
| Boje | Monochrome |
| Pozadinsko osvjetljenje | WLED |
| Sučelje | CPU |
| marka panela | TIANMA |
| panelni model | TM320240EGFWVSWD |
| vrsta panela | FSTN-LCD , LCM |
| veličina ploče | 5.7 inch |
| rezolucija | 320×240 , QVGA |
| način prikaza | STN, Black/White (Negative), Transmissive |
| aktivno područje | 115.17×86.37 mm |
| obris | 160×109×14 mm |
| površinski | |
| svjetlina | 60 cd/m² (Typ.) |
| omjer kontrasta | 8:1 (Typ.) |
| boje prikaza | Monochrome |
| vrijeme odziva | 200/160 (Typ.)(Tr/Td) |
| kut gledanja | 20/15/20/15 (Typ.)(CR≥2)(L/R/U/D) |
| tip svjetiljke | WLEDWithout Driver |
| signalno sučelje | 8-bit 6080/8080 parallel, 22 pins |
| ulazni napon | 5.0V (Typ.) |
| primjena | IA |
| AA057VG02 | Mitsubishi | 5.7 | 640×480 |
| EL320.240.36 AGL | Lumineq | 5.7 | 320×240 |
| FX050700DSCWDG12 | Data Image | 5.7 | |
| G057VTN01.1 | AUO | 5.7 | 640×480 |
| KG057QV1CA-G00 | Kyocera | 5.7 | 320×240 |
| KG057QV1CA-G04 | Kyocera | 5.7 | 320×240 |
| LM32015T | SHARP | 5.7 | 320×240 |
| LQ057Q3DC03 | SHARP | 5.7 | 320×240 |
| TM057KDHG10 | Tianma | 5.7 | 320×240 |
| TM320240EGFWVSWD | Tianma | 5.7 | 320×240 |
| AA084VC03 | Mitsubishi | 8.4 | 640×480 |
| DLC1210BBG | Other | 12.1 | 800×600 |
| DMF-51043NFU-FW-1 | Kyocera | 9.4 | 640×480 |
| G057QTN01.1 | AUO | 5.7 | 320×240 |
| LQ075V3DG01 | SHARP | 7.5 | 640×480 |
| LQ104V1DG33 | SHARP | 10.4 | 640×480 |
| NL10276BC12-02 | NLT | 6.3 | 1024×768 |
| NL128102AC28-07 | NLT | 18.1 | 1280×1024 |
| NL6448BC18-01 | NLT | 5.7 | 640×480 |
| TM080SDH01 | Tianma | 8.0 | 800×600 |
