| Broj dijela | TM027CDH04 |
| Marka | Tianma |
| Veličina | 2.7 |
| Primjena | DSC |
| Rezolucija | 320×240 |
| Sastav | LCM |
| Svjetlina | 300 |
| CR | 350:1 |
| Boje | 16.7M |
| Pozadinsko osvjetljenje | WLED |
| Sučelje | Serial RGB |
| marka panela | TIANMA |
| panelni model | TM027CDH04 |
| vrsta panela | a-Si TFT-LCD , LCM |
| veličina ploče | 2.7 inch |
| rezolucija | 320(RGB)×240 , QVGA |
| način prikaza | TN, Normally White, Transmissive |
| aktivno područje | 54×40.5 mm |
| obris | 63.5×46.6×2.8 mm |
| površinski | Clear, Hard coating (3H) |
| svjetlina | 300 cd/m² (Typ.) |
| omjer kontrasta | 350:1 (Typ.) |
| boje prikaza | 16.7M (8-bit), CIE193140% |
| vrijeme odziva | 25/40 (Typ./Max.)(Tr+Td) |
| kut gledanja | 50/50/25/55 (Typ.)(CR≥10)(L/R/U/D) |
| tip svjetiljke | 2S1PWLEDWithout Driver |
| signalno sučelje | Serial RGB (8-bit) + SPI, CCIR601/656, 39 pins |
| ulazni napon | 3.3V (Typ.) |
| primjena | DSC |
