| Broj dijela | TD024THEB2 |
| Marka | TPO |
| Veličina | 2.4 |
| Primjena | DSC |
| Rezolucija | 480×240 |
| Sastav | LCM |
| Svjetlina | 250 |
| CR | 300:1 |
| Boje | 16.7M |
| Pozadinsko osvjetljenje | WLED |
| Sučelje | Serial RGB |
| marka panela | TPO |
| panelni model | TD024THEB2 |
| vrsta panela | LTPS TFT-LCD , LCM |
| veličina ploče | 2.4 inch |
| rezolucija | 480×240 |
| način prikaza | TN, Normally White, Transmissive |
| aktivno područje | 48.05×35.76 mm |
| obris | 55.2×47.5 mm |
| površinski | Hard coating (3H) |
| svjetlina | 250 cd/m² (Typ.) |
| omjer kontrasta | 300:1 (Typ.) |
| boje prikaza | 16.7M (8-bit) |
| vrijeme odziva | |
| kut gledanja | 40/40/20/50 (Typ.)(CR≥10)(L/R/U/D) |
| tip svjetiljke | 1 pcsWLEDWithout Driver |
| signalno sučelje | Serial RGB (8-bit) + SPI, 40 pins |
| ulazni napon | 3.0V (Typ.) |
| rohs: | |
| primjena | DSC |
