| Broj dijela | QD14FL02 Rev.01 |
| Marka | QDI |
| Veličina | 14.1 |
| Primjena | NBPC |
| Rezolucija | 1400×1050 |
| Sastav | LCM |
| Svjetlina | 175 |
| CR | 300:1 |
| Boje | 262K |
| Pozadinsko osvjetljenje | CCFL |
| Sučelje | LVDS |
| marka panela | QDI |
| panelni model | QD14FL02 Rev.01 |
| vrsta panela | a-Si TFT-LCD , LCM |
| veličina ploče | 14.1 inch |
| rezolucija | 1400(RGB)×1050 , SXGA+ |
| način prikaza | TN, Normally White, Transmissive |
| aktivno područje | 285.7×214.3 mm |
| obris | 299×240.6×5.5 mm |
| stil oblika | Wedge (PCBA Bent, Depth ≥5.2mm) |
| površinski | Antiglare, Hard coating (3H) |
| svjetlina | 175 cd/m² (Typ.) |
| omjer kontrasta | 300:1 (Min.) |
| boje prikaza | 262K (6-bit), CIE193150% |
| vrijeme odziva | 10/15 (Typ.)(Tr/Td) |
| kut gledanja | 40/40/10/30 (Min.)(CR≥10)(L/R/U/D) |
| frekvencija | 60Hz |
| tip svjetiljke | 1 pcsCCFLEmbedded (Inverter) |
| signalno sučelje | LVDS (2 ch, 6-bit), 30 pins |
| ulazni napon | 3.3V (Typ.) |
| rohs: | |
| primjena | NBPC |
