| Broj dijela | B125XW01 V0 |
| Marka | AUO |
| Veličina | 12.5 |
| Primjena | NBPC |
| Rezolucija | 1366×768 |
| Sastav | LCM |
| Svjetlina | 200 |
| CR | 400:1 |
| Boje | 262K |
| Pozadinsko osvjetljenje | WLED |
| Sučelje | LVDS |
| marka panela | AUO |
| panelni model | B125XW01 V0 |
| vrsta panela | a-Si TFT-LCD , LCM |
| veličina ploče | 12.5 inch |
| rezolucija | 1366(RGB)×768 , WXGA |
| način prikaza | TN, Normally White, Transmissive |
| aktivno područje | 276.615×155.52 mm |
| obris | 300.4×179.5×3.6 mm |
| stil oblika | Flat (PCBA Flat, Depth 3.4~4.0mm) |
| površinski | Antiglare, Hard coating (3H), Reflection 4.3% (Typ.) |
| svjetlina | 200 cd/m² (Typ.) |
| omjer kontrasta | 400:1 (Typ.) |
| boje prikaza | 262K (6-bit), CIE193145% |
| vrijeme odziva | 16 (Typ.)(Tr+Td) |
| kut gledanja | 45/45/15/35 (Typ.)(CR≥10)(L/R/U/D) |
| frekvencija | 60Hz |
| tip svjetiljke | WLEDEmbedded (LED Driver) |
| signalno sučelje | LVDS (1 ch, 6-bit), 40 pins |
| ulazni napon | 3.3V (Typ.) |
| primjena | NBPC |
| B125XW01 V0 | AUO | 12.5 | 1366×768 |
| B125XW02 V0 | AUO | 12.5 | 1366×768 |
| LP125WF1-SPA2 | LG Display | 12.5 | 1920×1080 |
| LP125WF1-SPD1 | LG Display | 12.5 | 1920×1080 |
| LP125WH2-SLB2 | LG Display | 12.5 | 1366×768 |
| LP125WH2-SLB3 | LG Display | 12.5 | 1366×768 |
| LP125WH2-SPT1 | LG Display | 12.5 | 1366×768 |
| LP125WH2-TLD1 | LG Display | 12.5 | 1366×768 |
| M125NWN1 R0 | IVO | 12.5 | 1366×768 |
| M125NWR2 R1 | IVO | 12.5 | 1366×768 |
| B154EW08 V0 HW2A | AUO | 15.4 | 1280×800 |
| LP154W02-TL06 | LG Display | 15.4 | 1680×1050 |
| LP156WF6-SPB1 | LG Display | 15.6 | 1920×1080 |
| LP171WE3-TLA2 | LG Display | 17.1 | 1680×1050 |
| LTN121AT06-G01 | Samsung | 12.1 | 1280×800 |
| LTN141BT08-002 | Samsung | 14.1 | 1440×900 |
| LTN154AT01-A01 | Samsung | 15.4 | 1280×800 |
| LTN156HT02-B01 | Samsung | 15.6 | 1920×1080 |
| LTN160HT02-001 | Samsung | 16.0 | 1920×1080 |
| N141I1-L04 | Innolux | 14.1 | 1280×800 |
