| Broj dijela | N070ICN-GB1 |
| Marka | Innolux |
| Veličina | 7.0 |
| Primjena | PAD |
| Rezolucija | 800×1280 |
| Sastav | LCM |
| Svjetlina | 300 |
| CR | 800:1 |
| Boje | 16.7M |
| Pozadinsko osvjetljenje | WLED |
| Sučelje | MIPI |
| marka panela | INNOLUX |
| panelni model | N070ICN-GB1 |
| vrsta panela | a-Si TFT-LCD , LCM |
| veličina ploče | 7.0 inch |
| rezolucija | 800(RGB)×1280 , WXGA |
| način prikaza | IPS, Normally Black, Transmissive |
| aktivno područje | 94.2×150.72 mm |
| obris | 105.62×163.27×4.56 mm |
| površinski | Glare (Haze 0%), Hard coating (3H) |
| svjetlina | 300 cd/m² (Typ.) |
| omjer kontrasta | 800:1 (Typ.) |
| boje prikaza | 16.7M (8-bit), CIE193160% |
| vrijeme odziva | 11/9 (Typ.)(Tr/Td) |
| kut gledanja | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| frekvencija | 60Hz |
| tip svjetiljke | 3S6PWLEDWithout Driver |
| signalno sučelje | MIPI (4 data lanes), 31 pins |
| ulazni napon | 1.8/3.3V (Typ.)(VDDI/VCI) |
| primjena | PAD |
| AT070TN92 V.3 | Innolux | 7.0 | 800×480 |
| C070VW04 VB | AUO | 7.0 | 800×480 |
| N070ICE-G02 Rev.A2 | Innolux | 7.0 | 800×1280 |
| N070ICE-G02 Rev.C3 | Innolux | 7.0 | 800×1280 |
| N070ICE-GB1 | Innolux | 7.0 | 800×1280 |
| N070ICE-GB2 | Innolux | 7.0 | 800×1280 |
| N070ICG-LD1 | Innolux | 7.0 | 1280×800 |
| N070ICG-LD3 | Innolux | 7.0 | 1280×800 |
| N070ICG-LD4 | Innolux | 7.0 | 1280×800 |
| N070ICN-GB1 | Innolux | 7.0 | 800×1280 |
| B116XAN03.1 HW1A | AUO | 11.6 | 1366×768 |
| BP070WX1-300 | BOE | 7.0 | 800×1280 |
| CLAA101FP01 | CPT | 10.1 | 1920×1200 |
| HV121X03-100 | HYDIS | 12.1 | 1024×768 |
| LP125WH2-SPR1 | LG Display | 12.5 | 1366×768 |
| LTL101AL01-W01 | Samsung | 10.1 | 1280×800 |
| LTL101AL06-801 | Samsung | 10.1 | 1280×800 |
| LTL106HL01-001 | Samsung | 10.6 | 1920×1080 |
| NDS0708001280-31 | SEBO | 7.0 | 800×1280 |
| TPF0702002N | JDI | 7.0 | 1200×1920 |
