| Broj dijela | LTP400WQ-F01 |
| Marka | Samsung |
| Veličina | 4.0 |
| Primjena | PND |
| Rezolucija | 480×272 |
| Sastav | LCM |
| Svjetlina | 180 |
| CR | 300:1 |
| Boje | 16.7M |
| Pozadinsko osvjetljenje | WLED |
| Sučelje | TTL |
| marka panela | SAMSUNG |
| panelni model | LTP400WQ-F01 |
| vrsta panela | a-Si TFT-LCD , LCM |
| veličina ploče | 4.0 inch |
| rezolucija | 480(RGB)×272 , WQVGA |
| način prikaza | TN, Normally White, Transmissive |
| aktivno područje | 87.84×49.776 mm |
| obris | 98.3×62.6 mm |
| površinski | |
| svjetlina | 180 cd/m² (Typ.) |
| omjer kontrasta | 300:1 (Typ.) |
| boje prikaza | 16.7M (8-bit) |
| vrijeme odziva | 10/25 (Typ.)(Tr/Td) |
| kut gledanja | 65/65/55/50 (Typ.)(CR≥10)(L/R/U/D) |
| frekvencija | 60Hz |
| tip svjetiljke | 6S1PWLED |
| signalno sučelje | Parallel RGB (1 ch, 8-bit), 40 pins |
| ulazni napon | 2.5/5.0V (Typ.)(VDD/AVDD) |
| primjena | PND |
| AMS395GB04 | Samsung | 4.0 | 360×640 |
| AMS397GE66 | Samsung | 4.0 | 480×800 |
| DLC0400KZG | Other | 4.0 | 640×1136 |
| LB040Q03-TD01 | LG Display | 4.0 | 320×240 |
| LH400WS2-SD03 | LG Display | 4.0 | 640×1136 |
| LQ040Y3DX80 | SHARP | 4.0 | 480×800 |
| LT040MDU4100 | TOSHIBA | 4.0 | 480×854 |
| LTE400WQ-E01 | Samsung | 4.0 | 480×272 |
| LTM04C380K | TOSHIBA | 4.0 | 640×480 |
| LTP400WQ-F01 | Samsung | 4.0 | 480×272 |
| 35QVW1H | SII | 3.5 | 320×240 |
| AT050TN34 | Innolux | 5.0 | 480×272 |
| HSD050IDW1-A30 | HannStar | 5.0 | 800×480 |
| LB043WQ2-TD08 | LG Display | 4.3 | 480×272 |
| LMS430HF26 | Samsung | 4.3 | 480×272 |
| LTE400WQ-E01 | Samsung | 4.0 | 480×272 |
| LTE430WQ-F0B | Samsung | 4.3 | 480×272 |
| LTE480WV-F01 | Samsung | 4.8 | 800×480 |
| TM047NBH01 | Tianma | 4.7 | 480×272 |
| TM050NDH01 | Tianma | 5.0 | 480×272 |
