| Broj dijela | LTL070AL01-L01 |
| Marka | Samsung |
| Veličina | 7.0 |
| Primjena | UMPC |
| Rezolucija | 1280×800 |
| Sastav | LCM |
| Svjetlina | 400 |
| CR | 800:1 |
| Boje | 262K |
| Pozadinsko osvjetljenje | WLED |
| Sučelje | LVDS |
| marka panela | SAMSUNG |
| panelni model | LTL070AL01-L01 |
| vrsta panela | a-Si TFT-LCD , LCM |
| veličina ploče | 7.0 inch |
| rezolucija | 1280(RGB)×800 , WXGA |
| način prikaza | PLS, Normally Black, Transmissive |
| aktivno područje | 150.72×94.2 mm |
| obris | 164.2×106.75×4.42 mm |
| površinski | Glare (Haze 0%), Hard coating (2H), Reflection 1.2% (Typ.) |
| svjetlina | 400 cd/m² (Typ.) |
| omjer kontrasta | 800:1 (Typ.) |
| boje prikaza | 262K (6-bit), CIE193150% |
| vrijeme odziva | 30 (Typ.)(Tr+Td) |
| kut gledanja | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| frekvencija | 60Hz |
| tip svjetiljke | 6S4PWLEDWithout Driver |
| signalno sučelje | LVDS (1 ch, 6-bit), 31 pins |
| ulazni napon | 3.3V (Typ.) |
| primjena | UMPC |
