| Broj dijela | LTA121B860F |
| Marka | TOSHIBA |
| Veličina | 12.1 |
| Primjena | IA |
| Rezolucija | 800×600 |
| Sastav | LCM |
| Svjetlina | 380 |
| CR | 500:1 |
| Boje | 262K |
| Pozadinsko osvjetljenje | CCFL |
| Sučelje | TTL |
| marka panela | Toshiba Matsushita |
| panelni model | LTA121B860F |
| vrsta panela | a-Si TFT-LCD , LCM |
| veličina ploče | 12.1 inch |
| rezolucija | 800(RGB)×600 , SVGA |
| način prikaza | TN, Normally White, Transmissive |
| aktivno područje | 246×184.5 mm |
| obris | 278.3×209×11 mm |
| površinski | Hard coating |
| svjetlina | 380 cd/m² (Typ.) |
| omjer kontrasta | 500:1 (Typ.) |
| boje prikaza | 262K (6-bit) |
| vrijeme odziva | 30 (Typ.)(Tr+Td) |
| kut gledanja | 80/80/60/60 (Typ.)(CR≥10)(L/R/U/D) |
| frekvencija | 60Hz |
| tip svjetiljke | 2 pcsCCFLWithout Driver |
| signalno sučelje | Parallel RGB (1 ch, 6-bit), 32 pins |
| ulazni napon | 3.3V (Typ.) |
| primjena | IA |
