| Broj dijela | LQ088H9DZ03 |
| Marka | SHARP |
| Veličina | 8.8 |
| Primjena | CNS |
| Rezolucija | 640×240 |
| Sastav | LCM |
| Svjetlina | 250 |
| CR | 180:1 |
| Boje | 262K |
| Pozadinsko osvjetljenje | CCFL |
| Sučelje | TTL |
| marka panela | SHARP |
| panelni model | LQ088H9DZ03 |
| vrsta panela | a-Si TFT-LCD , LCM |
| veličina ploče | 8.8 inch |
| rezolucija | 640(RGB)×240 , HVGA |
| način prikaza | TN, Normally White, Transflective |
| aktivno područje | 209.28×78.48 mm |
| obris | 231.6×103.3 mm |
| površinski | Antiglare |
| svjetlina | 250 cd/m² (Typ.) |
| omjer kontrasta | 180:1 (Typ.)(Transmissive)8:1 (Typ.)(Reflective) |
| boje prikaza | 262K (6-bit) |
| vrijeme odziva | 10/15 (Typ.)(Tr/Td) |
| kut gledanja | 50/50/45/45 (Typ.)(CR≥15)(L/R/U/D) |
| tip svjetiljke | 2 pcsCCFLWithout Driver |
| signalno sučelje | Parallel RGB (1 ch, 6-bit), 31 pins |
| ulazni napon | 5/10/-10V (Typ.)(VSH/VGH/VGL) |
| primjena | CNS |
